Sunday Bikes "Park Ranger" 2020 BMX Frame

336.09 EUR- 15 %

284.83 EUR

Color | Brake Mounts | Top Tube Length
  • Please Select
Qty.
pick up in our shop?
Simply order online, choose as delivery method Pickup and pick up after receiving the pick-up confirmation.
Stuttgart Please select a product option!
Berlin Please select a product option!
  • Weight : 2.26kg / 4.98lbs
  • Packaging Unit: 1 Piece
  • Product ID (PID): 18712

The Sunday Bikes "Park Ranger" 2020 BMX Frame was designed for BMX Park. The Sunday Bikes "Park Ranger" 2020 BMX Frame comes with a short chain stay of 12.7" - 13", a headtube angle of 75.25° and a frame height of 7.625" which makes it very interesting for transition riding.

Facts: Sunday Bikes "Park Ranger" 2020 BMX Frame

  • Wheel Size: 20"
  • Material: 100% 4130 CrMo, hidden top tube and down tube gussets, butted tubes, tapered chainstays, integrated headset, removable brake hardware, Mid BB
  • Geometry:
    Top Tube Length (TT): 19.75", 20.75" or 21.0"
    Chainstay Length (CS): 12.7" (32.26cm) - 13" (33cm)
    Head Tube Angle (HA): 75.25°
    Seat Tube Angle (SA): 71°
    Bottom Bracket Height: 11.625" (29.53cm)
    Standover Height (SO): 7.625" (19.37cm)
  • Seat Clamp: integrated
  • Seat Post Diameter: 25.4mm
  • Bottom Bracket: Mid BB
  • Dropouts: 6mm thick, 14mm slots
  • Chain Tensioners: integrated
  • Brake Type: U-Brake
  • Brakemounts: with (screwable, M8)
  • Brakemounts included with delivery: Yes
  • Gyro compatible: Yes
  • Features: Modern transition BMX frame, Wide rear end for fat 2.4"
  • Model Year: 2020
